LK Systems
>
Products
>
Universal
>
Installation cabinets
>
Manifold cabinets
>
LK Manifold Cabinet UNI 550 L & XL

LK Manifold Cabinet UNI 550 L & XL

Variants
Detailed Information
Documentation
Related Products

Variants

Article	Width	Height	Depth	CO₂-EQ. (Kg)	Weight (kg)	Packaging	Item List
187 58 27	550 mm	550 mm	120 mm	14.08	7
187 58 28	550 mm	550 mm	145 mm	15.4	7,6

Width	550 mm
Height	550 mm
Depth	120 mm
CO₂-EQ. (Kg)	14.08
Weight (kg)	7
Packaging
Item list

Width	550 mm
Height	550 mm
Depth	145 mm
CO₂-EQ. (Kg)	15.4
Weight (kg)	7,6
Packaging
Item list

Detailed Information

Description

The LK Manifold Cabinets UNI 550 L and XL provide more space for supply pipe insulation. The cabinets are manufactured in powder coated steel plate in white RAL 9016, with a watertight base and 50 mm-high front edge.

The LK Drainage Elbow V2 is a complete package for exiting walls with leakage indication from the manifold cabinet. Protective bag included to pull over the cabinet while building is ongoing.

The cabinet will require additional sealing grommets. NOTE! Separate article:
• For a 25 mm conduit through an inlet hole, use the LK Pipe Inlet Conduit 25 (sealing grommet), Art. no. 187 44 83.
• For conduit/pipe sizes 12-34 mm through an inlet hole, use the LK Pipe Inlet UNI (sealing grommet), Art. no. 187 44 84.

For design and hatch range, see LK Manifold Cabinet UNI.

NOTE! The LK Base UNI is not intended for use with this cabinet.
