LKS1882700
LKS1882700
LKS1882700

LK Angle Wall Bracket Grip V2

  • Intended also for mounting on side of a stud
  • Compact design for small installation spaces
  • Three lockings provide secure attachment to the Angle Wall Support

LK Angle Wall Bracket Grip V2 is intended for pipe exits, through walls and floors. Use LK Angle Wall Bracket Grip V2 with a 25 mm conduit pipe and Universal pipe. A minimum of 55 mm free space in the wall is ...

Read more

LKS1882700

LK Angle Wall Bracket Grip V2

  • Variants
  • Detailed Information
  • Documentation
  • Videos
  • Related Products

Variants

Article Intended for For conduit dim. Color Packaging Item List
188 27 00 Angle Wall Support and stud. 25 mm Black

188 27 00

Intended for Angle Wall Support and stud.
For conduit dim. 25 mm
Color Black
Packaging
Item list

Detailed Information

Description

LK Angle Wall Bracket Grip V2 is intended for pipe exits, through walls and floors. Use LK Angle Wall Bracket Grip V2 with a 25 mm conduit pipe and Universal pipe.
A minimum of 55 mm free space in the wall is required to install the bracket. The LK Angle Wall Bracket Grip V2 can be attached to the LK Angle Wall Support, a cross studs / wood stud.
Two LK Angle Wall Brackets Grip V2 can be mounted and attached side to side with a measurement of 40 c/c between the pipe exits. If installing with a measurement of 60 c/c, use the LK Angle Wall Support.
The LK Bending Spring RSK 187 68 98 is a requirement if the LK PAL Universal Pipe A PiP is used with the LK Angle Wall Bracket Grip V2.
Use four 4,2x19 mm screws with a flat head when attaching the LK Angle Wall Bracket Grip V2 to a cross studs.
Use two 5x60 mm screws with a flat head when attaching the LK Angle Wall Bracket Grip V2 to a wood stud.
Screws are not supplied with the product and must be purchased separately.

Documentation

Product sheet

LK Angle Wall Bracket Grip V2

Assembly instruction

LK Angle Wall Bracket Grip V2
